A0014876JB | PRESTOLITE LEECE NEVILLE | ALTERNATOR

Specyfikacja produktu

Numer towaru A0014876JB
Numer sprzeda??y N/A
Numer serii 4800-4900
Notatka ALTERNATOR MADE FOR FORD. CUMMINS B ENGINE., -40C TO +110C, IGNITION TERMINAL 10-32
Napi?cie (V) 12
Amper 270
Typ mocowania J-180
Wymiary w INCHES
Obroty Zgodnie z wskaz??wkami zegara
Housing coating RAW
UL Approved No
Rozmiar ??ruby mocuj?cej 1/2-13 UNC
Ilo??? otwor??w mocuj?cych 1
Rozmiar plusowej ??ruby 5/16-18 UNC
Rozmiar minusowej ??ruby 3/8-16 UNC
Lokalizacja prostownika Wewn?trzna
Wymiar o??ki 7/8 INCH
Excitation type Ignition Excite
Lokalizacja regulatora Integralny
Numer regulatora R240103725
Diody wzbudzenia No
Ko??o pasowe Tak
Lamp driver No
Nastawny (regulowany) regulator No
Remote sense Tak
Smart check No
Batteryless No

Biuletyny techniczne

4000 Series Maintenance Manual Service manual for the 4000 series alternators with internal regulators and rectifiers
TSM1001_4000_Series_Int_Reg_and_Rectifier_Service-Manual.pdf (5.8 mb)
4000 Series Maintenance Manual - French Language Version French version of the 4000 Series internal regulator and rectified alternators service manual.
TSM1001_FR_4000_Series_Int_Reg_and_Rectifier_Service-Manual.pdf (5.9 mb)
4800 J180 Hardware Kit Hardware service kit for 4800 J180 series alternators.
TSB-3006_4800J180-hardware.pdf (1.3 mb)
Brush Inspection and Replacement Procedure Brush inspection and replacement procedure for 2500, 2800, 4800 and 4900 series alternators
TSB-1061_Brush_Insection_and_Replacement.pdf (898 kb)
Convert 4000 series alternators to solid lead frames Detailed instructions for converting 4000 series alternators with separate rectifier systems to the new solid lead frame rectifiers.
TSB-1062_4000-series-solid-lead-frame.pdf (2.9 mb)
Wire Identification Chart For R240 Regulators Wire Identification chart for R240 Regulators for 4800-4900 series alternators
TSB-1134_R240_Regulator_Wire_ID_Chart.pdf (85 kb)

Podział części

4000 Series J180 Mount Service Parts List Service parts list for 4000 series alternators utilizing the 12 diode rectifier systems.
SP1008-4000-J180-parts-list-web.pdf (2.7 mb)

Literatura

4000 Series High Amp Alternators 4000 Series High Amp alternators for all applications.
FL1165_4000_Series_Alternator_Flyer.pdf (645 kb)
